Kia Optima IV Sportswagon 2.0 CVVL (163 Hp) Automatic
Overall Rating
Kia Optima:
The Kia K5 , formerly known as the Kia Optima , is a mid-size car manufactured by Kia since 2000 and marketed globally through various nameplates. First generation cars were mostly marketed as the Optima, although the Kia Magentis name was used in Europe and Canada when sales began there in 2002. For the second-generation models, Kia used the Kia Lotze and Kia K5 name for the South Korean market, and the Magentis name globally, except in the United States, Canada, Malaysia and the Middle East, where the Optima name was retained until the 2021 model year. The K5 name is used for all markets since the introduction of the fifth generation in 2019....(Read more on Wikipedia)
IV Sportswagon Overview:
Kia Optima (IV Sportswagon). With 196 Nm of torque, it offers ample pulling power. It has moderate fuel consumption (~10.4 l/100km). With a weight of 1560 kg, it falls in the mid‑range. Front‑wheel drive delivers efficiency and easy handling. Acceleration is relatively slow (0–100 km/h in 10.7 s). The top speed reaches 205 km/h. A car with an extended rear cargo area, combining passenger comfort with increased storage. Seating for 5 makes it ideal for daily use.
2.0 CVVL (163 Hp) Automatic Verdict:
Performance Verdict
Offers adequate power for daily commuting and relaxed cruising, but acceleration is uninspiring for spirited driving.
Fuel Economy
Average fuel consumption for a naturally aspirated petrol engine with an automatic transmission in this segment.
Pros and Cons:
Pros:
- • Spacious and practical estate body with large boot capacity
- • Comfortable and refined ride quality
- • Stylish and distinctive design
- • Excellent warranty package
- • Wide range of efficient engines, including a plug-in hybrid
- • High safety ratings
Cons:
- • Some interior plastics can feel less premium than rivals
- • Infotainment system might feel dated on earlier models
- • Not as dynamically engaging as some European competitors
- • Higher trim levels can become expensive
Specifications:
Specifications are compared to those of the previous generation(IV: 2015 - 2018).
| General: | |
|---|---|
| Brand: | Kia |
| Model: | Optima |
| Generation: | IV Sportswagon |
| Modification (Engine): | 2.0 CVVL (163 Hp) Automatic |
| Start of production: | 2016 |
| End of production: | 2018 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | Station wagon (estate) |
| Seats: | 5 |
| Doors: | 5 |
| Engine: | |
|---|---|
| Power: | 163 Hp @ 6500 rpm. Same horsepower |
| Power per litre: | 81.5 Hp/l [Same length.] |
| Torque: | 196 Nm @ 4800 rpm. |
| Engine Model/Code: | G4ND More details about the engine G4ND |
| Engine displacement: | 1999 |
| Number of cylinders: | 4 |
| Engine configuration: | Inline |
| Number of valves per cylinder: | 4 |
| Fuel injection system: | Multi-port manifold injection |
| Engine aspiration: | Naturally aspirated engine |
| Engine oil capacity: | 4.3 l |
| Coolant: | 5.8 l |
| Engine layout: | Front, Transverse |
| Cylinder Bore: | 81 mm mm |
| Piston Stroke: | 97 mm mm |
| Compression ratio: | 10.3:1 |
| Performance: | |
|---|---|
| Fuel Type: | Petrol (Gasoline) |
| Fuel consumption (economy) - urban: | 10.4 l/100 km |
| Fuel consumption (economy) - extra urban: | 5.9 l/100 km |
| Fuel consumption (economy) - combined: | 7.6 l/100 km |
| Emission standard: | Euro 6 |
| Acceleration 0 - 100 km/h: | 10.7 sec |
| Acceleration 0 - 62 mph: | 10.7 sec |
| Maximum speed: | 205 km/h |
| Weight-to-power ratio: | 9.2 kg/Hp, 109 Hp/tonne |
| Weight-to-torque ratio: | 7.6 kg/Nm, 131.1 Nm/tonne |
| Acceleration 0 - 60 mph: | 10.2 sec |
| Space: | |
|---|---|
| Kerb Weight: | 1495-1625 |
| Max. weight: | 2090 |
| Max. roof load: | 100 kg |
| Max load: | 465-595 |
| Trunk (boot) space - maximum: | 1686 l |
| Trunk (boot) space - minimum: | 552 l |
| Permitted trailer load with brakes (12%): | 1300 kg |
| Fuel tank capacity: | 70 l |
| Permitted trailer load without brakes: | 650 kg |
| Permitted towbar download: | 80 kg |
| Size: | |
|---|---|
| Length: | 4855 mm mm [Same length.] |
| Width: | 1860 mm mm [Same width.] |
| Height: | 1470 mm mm [5mm more] |
| Wheelbase: | 2805 mm mm [Same wheelbase.] |
| Width including mirrors: | 2120 mm |
| Front track: | 1597-1607 mm |
| Rear (Back) track: | 1604-1614 mm |
| Front overhang: | 965 mm |
| Rear overhang: | 1085 mm |
| Ride height (ground clearance): | 135 mm |
| Minimum turning circle (turning diameter): | 10.9 m [above average] |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears | 6 |
| Transmission type | Automatic |
| Front brakes | Ventilated discs [Best for performance and cooling.] |
| Rear brakes | Disc [above average] |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/60 R16 95V; 215/55 R17 94W; 235/45 ZR18 98Y |
| Wheel rims size | 6.5J x 16; 7.5J x 17; 7.5J x 18 |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link suspension |
