Everything you need to know about specifications and performance - Cupra Formentor 2024 - 1.5 TSI (204 Hp) e-Hybrid DSG

Overview:

What is the engine capacity of a Cupra Formentor 2024?
The engine capacity of the Cupra Formentor 2024 is 1498.

Cupra Formentor 2024 How many horsepower?
The engine power of the Cupra Formentor 2024 is 150 Hp @ 5000-6000 rpm..

What is the Cupra Formentor 2024 engine?
Cupra Formentor 2024 engine is DUC. (Click to see other cars using the same engine)

How powerful is the electrical system in the Cupra Formentor 2024?
The power of the electrical system in the Cupra Formentor 2024 is 204 Hp hp.

General:

Brand: Cupra

Model: Formentor

Generation: facelift 2024

Modification (Engine): 1.5 TSI (204 Hp) e-Hybrid DSG

Start of production: July, 2024

End of production:

Powertrain Architecture:Plug-In Hybrid Electric Vehicles (PHEVs)

Body type: SUV, Crossover

Seats: 5

Doors: 5

Engine:

Engine systems: Start & Stop System

Power: 150 hp @ 5000-6000 rpm.

Power per litre: 100.1 hp/l

Torque: 250 nm @ 1500-4000 rpm.

Engine Model/Code:DUC

Engine displacement: 1498

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Direct injection

Engine aspiration: Turbocharger, Intercooler

Engine layout: Front, Transverse

Cylinder Bore: 74.5 mm

Piston Stroke: 85.9 mm

Compression ratio: 11.5:1

Performance:

Fuel Type: Petrol / electricity

Combined fuel consumption (WLTP): 0.4-0.5 l/100 km

Emission standard: Euro 6 EA

Acceleration 0 - 100 km/h: 7.9 sec

Acceleration 0 - 62 mph: 7.9 sec

Maximum speed: 210 km/h

Weight-to-power ratio: 8 kg/Hp, 124.2 Hp/tonne

Weight-to-torque ratio: 4.7 kg/Nm, 213.2 Nm/tonne

Max speed (electric): 130 km/h

Acceleration 0 - 60 mph: 7.5 sec

Electric system:

Net (usable) battery capacity: 19.7 kWh

Gross battery capacity: 25.8 kWh

Battery technology: Lithium-ion (Li-Ion)

Battery location: Below the floor, under the rear seats

System power: 204 hp

System torque: 350 nm

All-electric range: 115-125 km

Electric motor power: 116 hp

Average Energy consumption: 16.1-17.2 kWh/100 km

Electric motor location: Between the combustion Engine and the transmission

Average Energy consumption (WLTP): 16.1-17.2 kWh/100 km

All-electric range (WLTP): 115-125 km

Space:

Kerb Weight (kg): 1642

Max. weight (kg): 2190

Max. roof load: 75 kg

Max load (kg): 548

Trunk (boot) space - minimum: 345 l

Permitted trailer load with brakes (12%): 1700 kg

Fuel tank capacity: 40 l

Permitted trailer load without brakes: 750 kg

Permitted towbar download: 80 kg

dimensions:

Length: 4451 mm

Width: 1839 mm

Height: 1537 mm

wheelbase: 2679 mm

Front track: 1583 mm

Rear (Back) track: 1555 mm

Minimum turning circle (turning diameter): 11.4 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

Drive wheel: Front wheel drive

Number of gears and type of gearbox: 6 gears, automatic transmission DSG

Front brakes: Ventilated discs

Rear brakes: Ventilated discs

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Electric Steering

Tires size: 245/45 R18; 245/40 R19

Wheel rims size: 8J x 18; 8J x 19

Front suspension: Independent type McPherson

Rear suspension: Independent multi-link suspension
