Everything you need to know about specifications and performance - Volkswagen Tiguan 2019 - 2.0 TDI (190 Hp) 4MOTION DSG

Full specifications and technical details 2019 Volkswagen Tiguan II Allspace 2.0 TDI (190 Hp) 4MOTION DSG

Overview:

What is the engine capacity of a Volkswagen Tiguan 2019?
The engine capacity of the Volkswagen Tiguan 2019 is 1968.

Volkswagen Tiguan 2019 How many horsepower?
The engine power of the Volkswagen Tiguan 2019 is 190 Hp @ 3500-4000 rpm..

What is the Volkswagen Tiguan 2019 engine?
Volkswagen Tiguan 2019 engine is EA288 / DFHA. (Click to see other cars using the same engine)

How much gasoline does a Volkswagen Tiguan 2019 consume?
The Volkswagen Tiguan 2019 consumes 5.5-5.6 liters of gasoline per 100 km

General:

Brand: Volkswagen

Model: Tiguan

Generation: II Allspace

Modification (Engine): 2.0 TDI (190 Hp) 4MOTION DSG

Start of production: December, 2019

End of production: 2020

Powertrain Architecture: Internal Combustion Engine

Body type:Sports Utility Vehicle (SUV)

Seats: 7

Doors: 5

Engine:

Engine systems: Start & Stop System

Power: 190 hp @ 3500-4000 rpm.

Power per litre: 96.5 hp/l

Torque: 400 nm @ 1900-3300 rpm.

Engine Model/Code:EA288 / DFHA

Engine displacement: 1968

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Diesel Commonrail

Engine aspiration: Turbocharger, Intercooler

Engine oil capacity: 4.7 l

Engine layout: Front, Transverse

Cylinder Bore: 81 mm

Piston Stroke: 95.5 mm

Performance:

Fuel Type: Diesel

Fuel consumption (economy) - urban: 6.3-6.4 l/100 km

Fuel consumption (economy) - extra urban: 4.9-5.1 l/100 km

Fuel consumption (economy) - combined: 5.5-5.6 l/100 km

Emission standard: Euro 6d-TEMP-EVAP-ISC

Acceleration 0 - 100 km/h: 8.2 sec

Acceleration 0 - 62 mph: 8.2 sec

Maximum speed: 210 km/h

Weight-to-power ratio: 9.1 kg/Hp, 109.8 Hp/tonne

Weight-to-torque ratio: 4.3 kg/Nm, 231.2 Nm/tonne

Acceleration 0 - 60 mph: 7.8 sec

Space:

Kerb Weight (kg): 1730

Max. weight (kg): 2400

Max. roof load: 75 kg

Max load (kg): 670

Trunk (boot) space - maximum: 1775 l

Trunk (boot) space - minimum: 230 l

Permitted trailer load with brakes (12%): 2400 kg

Fuel tank capacity: 60 l

AdBlue tank: 12 l

Permitted trailer load without brakes: 750 kg

Permitted towbar download: 100 kg

dimensions:

Ramp-over (brakeover) angle: 14.9°

Length: 4701 mm

Width: 1839 mm

Height: 1674 mm

wheelbase: 2787 mm

Width including mirrors: 2099 mm

Front track: 1575-1585 mm

Rear (Back) track: 1564-1574 mm

Ride height (ground clearance): 201 mm

Minimum turning circle (turning diameter): 11.9 m

Approach angle: 16.9°

Departure angle: 14.5°

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.

Drive wheel: All wheel drive (4x4)

Number of gears and type of gearbox: 7 gears, automatic transmission DSG

Front brakes: Ventilated discs

Rear brakes: Disc

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Electric Steering

Tires size: 235/55 R18

Wheel rims size: 7J x 18
