Volkswagen Caravelle T4 2.0 (84 Hp)
Overall Rating
Volkswagen Caravelle:
Volkswagen Caravelle is the nameplate of a van based on the Volkswagen Transporter. For information about the Caravelle, refer to the regular Transporter articles:....(Read more on Wikipedia)
T4 Overview:
Volkswagen Caravelle (T4). With 159 Nm of torque, it offers ample pulling power. With a weight of 1565 kg, it falls in the mid‑range. Front‑wheel drive delivers efficiency and easy handling. The top speed reaches 144 km/h. A large vehicle designed for transporting goods or groups of people. With seating for 6, it’s perfect for larger families.
The Volkswagen Caravelle T4 was produced before Euro NCAP testing began in 1997 and was not officially rated. As an older vehicle, it lacks modern active and passive safety features found in contemporary vans.
2.0 (84 Hp) Verdict:
Performance Verdict
An entry-level petrol engine, offering just enough power for city driving and light loads. Struggles significantly on highways or with a full complement of passengers/cargo.
Fuel Economy
This petrol engine is quite thirsty for its power output. Expect frequent trips to the fuel station, especially in urban driving.
Community Verdict
This rating is based on comments found on Reddit, scanned using artificial intelligence, and may not accurately reflect reality.
4.4 / 5
Based on AI analysis of 7 discussions
Read What Owners Say
Pros and Cons:
Pros:
- • Exceptional reliability and durability, especially the diesel engines
- • Highly versatile and spacious interior, ideal for conversions or large families
- • Strong aftermarket support and parts availability
- • Comfortable driving position and good visibility for a van
- • Robust build quality that stands the test of time
Cons:
- • Petrol engines are very thirsty, leading to high running costs
- • Naturally aspirated diesel engines are significantly underpowered
- • Lack of modern safety features due to its age
- • Prone to rust, especially in older, unmaintained examples
- • Can be noisy at highway speeds, particularly the diesel variants
Specifications:
Specifications are compared to those of the previous generation(T3: 1987 - 1992).
| General: | |
|---|---|
| Brand: | Volkswagen |
| Model: | Caravelle |
| Generation: | T4 |
| Modification (Engine): | 2.0 (84 Hp) |
| Start of production: | 1990 |
| End of production: | 1995 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | Van |
| Seats: | 6-9 |
| Doors: | 4-5 |
| Engine: | |
|---|---|
| Power: | 84 Hp @ 4300 rpm. Same horsepower |
| Power per litre: | 42.7 Hp/l [55mm more] |
| Torque: | 159 Nm @ 2200 rpm. |
| Engine Model/Code: | AAC More details about the engine AAC |
| Engine displacement: | 1968 |
| Number of cylinders: | 4 |
| Engine configuration: | Inline |
| Number of valves per cylinder: | 2 |
| Fuel injection system: | Multi-port manifold injection |
| Engine aspiration: | Naturally aspirated engine |
| Valvetrain: | SOHC |
| Engine oil capacity: | 5 l |
| Coolant: | 9 l |
| Engine layout: | Front, Transverse |
| Cylinder Bore: | 81 mm mm |
| Piston Stroke: | 95.5 mm mm |
| Compression ratio: | 8.5:1 |
| Performance: | |
|---|---|
| Fuel Type: | Petrol (Gasoline) |
| Fuel consumption (economy) - urban: | 13.9 l/100 km |
| Fuel consumption (economy) - extra urban: | 9.1 l/100 km |
| Maximum speed: | 144 km/h |
| Weight-to-power ratio: | 18.6 kg/Hp, 53.7 Hp/tonne |
| Weight-to-torque ratio: | 9.8 kg/Nm, 101.6 Nm/tonne |
| Space: | |
|---|---|
| Kerb Weight: | 1565 |
| Max. weight: | 2465-2650 |
| Max. roof load: | 100 kg |
| Max load: | 900-1085 |
| Trunk (boot) space - maximum: | 5400 l |
| Permitted trailer load with brakes (12%): | 2000 kg |
| Fuel tank capacity: | 80 l |
| Permitted trailer load without brakes: | 700 kg |
| Permitted towbar download: | 100 kg |
| Size: | |
|---|---|
| Length: | 4655 mm mm [55mm more] |
| Width: | 1840 mm mm [5mm less] |
| Height: | 1940 mm mm [80mm less] |
| Wheelbase: | 2920 mm mm [440mm more] |
| Front track: | 1589 mm |
| Rear (Back) track: | 1554 mm |
| Front overhang: | 860 mm |
| Rear overhang: | 875 mm |
| Ride height (ground clearance): | 180 mm |
| Minimum turning circle (turning diameter): | 11.7 m [above average] |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears | 5 |
| Transmission type | Manual |
| Front brakes | Disc [bad for performance and cooling.] |
| Rear brakes | Drum [bad for performance and cooling.] |
| Steering type | Steering rack and pinion |
| Tires size | 195/70 R15; 205/65 R15; 215/65 R15 |
| Wheel rims size | 6J x 15; 7J x 15 |
| Front suspension | Independent torsion bar, double wishbone, Transverse stabilizer |
| Rear suspension | Independent coil spring, Trailing arm |
