Everything you need to know about specifications and performance - Nissan Navara 2015 - 2.3 dCi (160 Hp) AWD

Full specifications and technical details 2015 Nissan Navara IV King Cab 2.3 dCi (160 Hp) AWD

Overview:

What is the engine capacity of a Nissan Navara 2015?
The engine capacity of the Nissan Navara 2015 is 2299.

Nissan Navara 2015 How many horsepower?
The engine power of the Nissan Navara 2015 is 160 Hp @ 3750 rpm..

What is the Nissan Navara 2015 engine?
Nissan Navara 2015 engine is YS23DDT. (Click to see other cars using the same engine)

How much gasoline does a Nissan Navara 2015 consume?
The Nissan Navara 2015 consumes 6.4 liters of gasoline per 100 km

General:

Brand: Nissan

Model: Navara

Generation: IV King Cab

Modification (Engine): 2.3 dCi (160 Hp) AWD

Start of production: 2015

End of production: 2019

Powertrain Architecture: Internal Combustion Engine

Body type:Pickup

Seats: 4

Doors: 4

Engine:

Engine systems: Particulate filter

Power: 160 hp @ 3750 rpm.

Power per litre: 69.6 hp/l

Torque: 403 nm @ 1500-2500 rpm.

Engine Model/Code:YS23DDT

Engine displacement: 2299

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Diesel Commonrail

Engine aspiration: Turbocharger, Intercooler

Valvetrain: DOHC

Engine oil capacity: 6.4 l

Coolant: 11.1 l

Engine layout: Front, Transverse

Cylinder Bore: 85 mm

Piston Stroke: 101.3 mm

Compression ratio: 15.4:1

Performance:

Fuel Type: Diesel

Fuel consumption (economy) - urban: 7 l/100 km

Fuel consumption (economy) - extra urban: 6.1 l/100 km

Fuel consumption (economy) - combined: 6.4 l/100 km

Emission standard: Euro 5b

Acceleration 0 - 100 km/h: 12 sec

Acceleration 0 - 62 mph: 12 sec

Maximum speed: 172 km/h

Weight-to-power ratio: 11.4 kg/Hp, 87.7 Hp/tonne

Weight-to-torque ratio: 4.5 kg/Nm, 220.9 Nm/tonne

Acceleration 0 - 60 mph: 11.4 sec

Space:

Kerb Weight (kg): 1824

Max. weight (kg): 3010

Max load (kg): 1186

Permitted trailer load with brakes (12%): 3500 kg

Fuel tank capacity: 80 l

Permitted trailer load without brakes: 750 kg

Permitted towbar download: 140 kg

dimensions:

Ramp-over (brakeover) angle: 22°

Wading depth: 600 mm

Length: 5255 mm

Width: 1850 mm

Height: 1780-1790 mm

wheelbase: 3150 mm

Width including mirrors: 2085 mm

Front track: 1570 mm

Rear (Back) track: 1570 mm

Front overhang: 870 mm

Rear overhang: 1235 mm

Ride height (ground clearance): 208-223 mm

Minimum turning circle (turning diameter): 11.8 m

Approach angle: 29.4-30.4°

Departure angle: 24.6-25.6°

Powertrain, Suspension and Brakes:

Drive wheel: All wheel drive (4x4)

Number of gears and type of gearbox: 6 gears, manual transmission

Front brakes: Ventilated discs

Rear brakes: Drum

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Electric Steering

Tires size: 255/70 R16; 255/60 R18

Wheel rims size: 7J x 16; 7J x 18

Front suspension: Double wishbone

Rear suspension: Leaf Spring
