Everything you need to know about specifications and performance - Fiat Ulysse 2002 - 2.2 16V JTD (128 Hp)

gray symbol cars image

Overview:

What is the engine capacity of a Fiat Ulysse 2002?
The engine capacity of the Fiat Ulysse 2002 is 2179.

Fiat Ulysse 2002 How many horsepower?
The engine power of the Fiat Ulysse 2002 is 128 Hp @ 4000 rpm..

What is the Fiat Ulysse 2002 engine?
Fiat Ulysse 2002 engine is 4HW DW12ATED4. (Click to see other cars using the same engine)

How much gasoline does a Fiat Ulysse 2002 consume?
The Fiat Ulysse 2002 consumes 7.4 liters of gasoline per 100 km

General:

Brand: Fiat
Model: Ulysse
Generation: II (179)
Modification (Engine): 2.2 16V JTD (128 Hp)
Start of production: 2002
End of production: 2006
Powertrain Architecture: Internal Combustion Engine
Body type: Minivan, Multi Purpose Vehicle (MPV)
Seats: 5
Doors: 5

Engine:

Power: 128 hp @ 4000 rpm.
Power per litre: 58.7 hp/l
Torque: 314 nm @ 2000 rpm.
Engine Model/Code:4HW DW12ATED4
Engine displacement: 2179
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 4
Fuel injection system: Diesel Commonrail
Engine aspiration: Turbocharger, Intercooler
Engine oil capacity: 4.75 l
Coolant: 11.3 l
Engine layout: Front, Transverse
Cylinder Bore: 85 mm
Piston Stroke: 96 mm
Compression ratio: 17.6:1

Performance:

Fuel Type: Diesel
Fuel consumption (economy) - urban: 10.1 l/100 km
Fuel consumption (economy) - extra urban: 5.9 l/100 km
Fuel consumption (economy) - combined: 7.4 l/100 km
Acceleration 0 - 100 km/h: 12.6 sec
Acceleration 0 - 62 mph: 12.6 sec
Maximum speed: 182 km/h
Weight-to-power ratio: 13.9 kg/Hp, 71.8 Hp/tonne
Weight-to-torque ratio: 5.7 kg/Nm, 176.1 Nm/tonne
Acceleration 0 - 60 mph: 12 sec

Space:

Kerb Weight (kg): 1783
Max. weight (kg): 2505
Max load (kg): 722
Trunk (boot) space - maximum: 2948 l
Trunk (boot) space - minimum: 324 l
Fuel tank capacity: 80 l

dimensions:

Length: 4730 mm
Width: 1850 mm
Height: 1750 mm
wheelbase: 2825 mm
Front track: 1570 mm
Rear (Back) track: 1600 mm

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 5 gears, manual transmission
Front brakes: Ventilated discs
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Hydraulic Steering
Tires size: 215/65 R15
Wheel rims size: 6.5J x 15
Front suspension: Spring Strut
Rear suspension: Coil Spring
