Everything you need to know about specifications and performance - ChangAn CS35 2017 - 1.5T (156 Hp)

Full specifications and technical details 2017 ChangAn CS35 (facelift 2017) 1.5T (156 Hp)

Overview:

What is the engine capacity of a ChangAn CS35 2017?
The engine capacity of the ChangAn CS35 2017 is 1468.

ChangAn CS35 2017 How many horsepower?
The engine power of the ChangAn CS35 2017 is 156 Hp @ 5000 rpm..

What is the ChangAn CS35 2017 engine?
ChangAn CS35 2017 engine is 4G15T. (Click to see other cars using the same engine)

What is the recommended oil for a ChangAn CS35 2017 engine?
The recommended oil for a ChangAn CS35 2017 car engine is 5W-30.

What type of camshaft transmission system is used in a ChangAn CS35 2017 engine?
belt is used to transmit motion.

General:

Brand: ChangAn
Model: CS35
Generation: facelift 2017
Modification (Engine): 1.5T (156 Hp)
Start of production: 2017
End of production:
Powertrain Architecture: Internal Combustion Engine
Body type:Sports Utility Vehicle (SUV)
Seats: 5
Doors: 5

Engine:

Power: 156 hp @ 5000 rpm.
Power per litre: 106.3 hp/l
Torque: 210 nm @ 2000-4500 rpm.
Engine Model/Code:4G15T
Engine displacement: 1468
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 4
Fuel injection system: Multi-port manifold injection
Engine aspiration: Turbocharger, Intercooler
Valvetrain: DOHC
Engine layout: Front, Transverse
Cylinder Bore: 75.5 mm
Piston Stroke: 82 mm
recommended engine oil: 5W-30
euro standards: EURO 4/5
engine lifespan (km): ~250 000
weight (kg): 145 (with attachments)
timing drive: belt

Show more details about this engine

Performance:

Fuel Type: Petrol (Gasoline)
Emission standard: Euro 5
Weight-to-power ratio: 8.6 kg/Hp, 116.4 Hp/tonne
Weight-to-torque ratio: 6.4 kg/Nm, 156.7 Nm/tonne

Space:

Kerb Weight (kg): 1340
Trunk (boot) space - maximum: 1058 l
Trunk (boot) space - minimum: 348 l
Fuel tank capacity: 52 l

dimensions:

Length: 4170 mm
Width: 1810 mm
Height: 1670 mm
wheelbase: 2560 mm
Front track: 1560 mm
Rear (Back) track: 1560 mm
Ride height (ground clearance): 180 mm
Minimum turning circle (turning diameter): 10 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 5 gears, manual transmission
Front brakes: Ventilated discs
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: 215/50 R17
Wheel rims size: 7J x 17
Front suspension: Independent type McPherson, Transverse stabilizer
Rear suspension: Torsion
