BMW 5 Series E28 524d (86 Hp)
Overall Rating
BMW 5 Series:
The BMW 5 Series is an executive car manufactured and marketed by BMW since 1972. It is the successor to the BMW New Class sedans and is currently in its eighth generation. The car is sold as either a sedan or, since 1991, a station wagon. A 5-door fastback was sold between 2009 and 2017. Each successive generation has been given an internal G-code designation since 2017. Previously, a F-code designation was used between 2010 and 2016, while an E-code designation was used between 1972 and 2010. These are used to distinguish each model and generation from each other....(Read more on Wikipedia)
E28 Overview:
BMW 5 Series (E28). With 153 Nm of torque, it offers ample pulling power. It has moderate fuel consumption (~9.2 l/100km). With a weight of 1330 kg, it falls in the mid‑range. Rear‑wheel drive offers dynamic handling and sporty feedback. Acceleration is relatively slow (0–100 km/h in 18.1 s). The top speed reaches 164 km/h. A four-door car with a separate trunk, ideal for families and daily commuting. Seating for 5 makes it ideal for daily use.
524d (86 Hp) Verdict:
Performance Verdict
Basic performance, designed purely for economy and durability rather than speed, resulting in very leisurely acceleration.
Fuel Economy
Excellent fuel economy, making it a highly cost-effective option for long-distance travel.
Pros and Cons:
Pros:
- • Timeless, elegant design with classic BMW aesthetics.
- • Engaging driving dynamics and responsive steering.
- • Robust and durable inline-six engines (M30, M20).
- • Comfortable and well-built interior for its era.
- • Strong enthusiast following and good parts availability.
- • Potential for appreciating classic car value.
Cons:
- • Lacks modern safety features and crash protection.
- • Prone to rust in common areas if not maintained.
- • Older technology, including basic infotainment and driver aids.
- • Fuel economy can be poor on larger, performance-oriented engines.
- • Maintenance costs can be high for neglected examples or specific parts.
Specifications:
Specifications are compared to those of the previous generation(E28: 1985 - 1987).
| General: | |
|---|---|
| Brand: | BMW |
| Model: | 5 Series |
| Generation: | E28 |
| Modification (Engine): | 524d (86 Hp) |
| Start of production: | 1986 |
| End of production: | 1987 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | Sedan |
| Seats: | 5 |
| Doors: | 4 |
| Engine: | |
|---|---|
| Power: | 86 Hp @ 4600 rpm. Same horsepower |
| Power per litre: | 35.2 Hp/l [Same length.] |
| Torque: | 153 Nm @ 2500 rpm. |
| Engine Model/Code: | M21D24 More details about the engine M21D24 |
| Engine displacement: | 2443 |
| Number of cylinders: | 6 |
| Engine configuration: | Inline |
| Number of valves per cylinder: | 2 |
| Fuel injection system: | Precombustion chamber injection |
| Engine aspiration: | Naturally aspirated engine |
| Engine oil capacity: | 5.3 l |
| Engine layout: | Front, Longitudinal |
| Cylinder Bore: | 80 mm |
| Piston Stroke: | 81 mm |
| Compression ratio: | 22:1 |
| Performance: | |
|---|---|
| Fuel Type: | Diesel |
| Fuel consumption (economy) - urban: | 9.2 l/100 km |
| Fuel consumption (economy) - extra urban: | 5.6 l/100 km |
| Fuel consumption (economy) - combined: | 7.5 l/100 km |
| Acceleration 0 - 100 km/h: | 18.1 sec |
| Acceleration 0 - 62 mph: | 18.1 sec |
| Maximum speed: | 164 km/h |
| Weight-to-power ratio: | 15.5 kg/Hp, 64.7 Hp/tonne |
| Weight-to-torque ratio: | 8.7 kg/Nm, 115 Nm/tonne |
| Acceleration 0 - 60 mph: | 17.2 sec |
| Space: | |
|---|---|
| Kerb Weight: | 1330 |
| Trunk (boot) space - minimum: | 460 l |
| Fuel tank capacity: | 70 l |
| Size: | |
|---|---|
| Length: | 4620 mm [Same length.] |
| Width: | 1700 mm [Same width.] |
| Height: | 1415 mm [Same height.] |
| Wheelbase: | 2625 mm [Same wheelbase.] |
| Front track: | 1430 mm |
| Rear (Back) track: | 1470 mm |
| Ride height (ground clearance): | 140 mm |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears | 5 |
| Transmission type | Manual |
| Front brakes | Disc |
| Rear brakes | Disc |
