Everything you need to know about specifications and performance - Volkswagen Passat 1993 - 2.0 16V (150 Hp)

gray symbol cars image

Overview:

What is the engine capacity of a Volkswagen Passat 1993?
The engine capacity of the Volkswagen Passat 1993 is 1984.

Volkswagen Passat 1993 How many horsepower?
The engine power of the Volkswagen Passat 1993 is 150 Hp @ 6000 rpm..

What is the Volkswagen Passat 1993 engine?
Volkswagen Passat 1993 engine is ABF. (Click to see other cars using the same engine)

How much gasoline does a Volkswagen Passat 1993 consume?
The Volkswagen Passat 1993 consumes 9 liters of gasoline per 100 km

General:

Brand: Volkswagen
Model: Passat
Generation: Variant (B4)
Modification (Engine): 2.0 16V (150 Hp)
Start of production: 1993
End of production: 1997
Powertrain Architecture: Internal Combustion Engine
Body type:Station wagon
Seats: 5
Doors: 5

Engine:

Power: 150 hp @ 6000 rpm.
Power per litre: 75.6 hp/l
Torque: 180 nm @ 4800 rpm.
Engine Model/Code:ABF
Engine displacement: 1984
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 4
Fuel injection system: Multi-port manifold injection
Engine aspiration: Naturally aspirated Engine
Valvetrain: DOHC
Engine oil capacity: 4 l
Coolant: 5 l
Engine layout: Front, Transverse
Cylinder Bore: 82.5 mm
Piston Stroke: 92.8 mm
Compression ratio: 10.5:1

Performance:

Fuel Type: Petrol (Gasoline)
Fuel consumption (economy) - urban: 12.2 l/100 km
Fuel consumption (economy) - extra urban: 6.5 l/100 km
Fuel consumption (economy) - combined: 9 l/100 km
Emission standard: Euro 2
Acceleration 0 - 100 km/h: 9.9 sec
Acceleration 0 - 62 mph: 9.9 sec
Maximum speed: 199 km/h
Weight-to-power ratio: 9 kg/Hp, 111.5 Hp/tonne
Weight-to-torque ratio: 7.5 kg/Nm, 133.8 Nm/tonne
Acceleration 0 - 60 mph: 9.4 sec

Space:

Kerb Weight (kg): 1345
Max. weight (kg): 1890
Max. roof load: 75 kg
Max load (kg): 545
Trunk (boot) space - maximum: 1500 l
Trunk (boot) space - minimum: 465 l
Permitted trailer load with brakes (12%): 1500 kg
Fuel tank capacity: 70 l
Permitted trailer load without brakes: 650 kg

dimensions:

Length: 4595 mm
Width: 1720 mm
Height: 1445 mm
wheelbase: 2625 mm
Front track: 1485 mm
Rear (Back) track: 1428 mm
Front overhang: 915 mm
Rear overhang: 1055 mm
Minimum turning circle (turning diameter): 10.7 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 5 gears, manual transmission
Front brakes: Ventilated discs
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Hydraulic Steering
Tires size: 205/50 R15
Wheel rims size: 6J x 15
Front suspension: Coil spring, Wishbone, Transverse stabilizer
Rear suspension: Wishbone, Transverse stabilizer, Coil Spring
