Everything you need to know about specifications and performance - Volkswagen Golf 2017 - GTE 1.4 TSI (204 Hp) Plug-in Hybrid DSG
Overview:
What is the engine capacity of a Volkswagen Golf 2017?
The engine capacity of the Volkswagen Golf 2017 is 1395.
Volkswagen Golf 2017 How many horsepower?
The engine power of the Volkswagen Golf 2017 is 150 Hp @ 5000-6000 rpm..
What is the Volkswagen Golf 2017 engine?
Volkswagen Golf 2017 engine is EA211 / CUKB. (Click to see other cars using the same engine)
How powerful is the electrical system in the Volkswagen Golf 2017?
The power of the electrical system in the Volkswagen Golf 2017 is 204 Hp hp.
How much gasoline does a Volkswagen Golf 2017 consume?
The Volkswagen Golf 2017 consumes 1.6-1.8 liters of gasoline per 100 km
General:
Brand: Volkswagen
Model: Golf
Generation: VII (5-door, facelift 2017)
Modification (Engine): GTE 1.4 TSI (204 Hp) Plug-in Hybrid DSG
Start of production: March, 2017
End of production: May, 2018
Powertrain Architecture:Plug-In Hybrid Electric Vehicles (PHEVs)
Body type:Hatchback
Seats: 5
Doors: 5
Engine:
Engine systems: Start & Stop System
Power: 150 hp @ 5000-6000 rpm.
Power per litre: 107.5 hp/l
Torque: 250 nm @ 1500-3500 rpm.
Engine Model/Code:EA211 / CUKB
Engine displacement: 1395
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 4
Fuel injection system: Direct injection
Engine aspiration: Turbocharger, Intercooler
Valvetrain: DOHC
Engine oil capacity: 4 l
Engine layout: Front, Transverse
Cylinder Bore: 74.5 mm
Piston Stroke: 80 mm
Compression ratio: 10:1
Performance:
Fuel Type: Petrol / electricity
Fuel consumption (economy) - combined (NEDC, WLTP equivalent): 1.6-1.8 l/100 km
Fuel consumption (economy) - combined: 1.6-1.8 l/100 km
Emission standard: Euro 6
Acceleration 0 - 100 km/h: 7.6 sec
Acceleration 0 - 62 mph: 7.6 sec
Maximum speed: 222 km/h
Weight-to-power ratio: 7.5 kg/Hp, 132.5 Hp/tonne
Weight-to-torque ratio: 4.4 kg/Nm, 227.3 Nm/tonne
Acceleration 0 - 60 mph: 7.2 sec
Electric system:
Gross battery capacity: 8.7 kWh
Battery technology: Lithium-ion (Li-Ion)
Battery location: Under the rear seats
System power: 204 hp
System torque: 350 nm
All-electric range: 45-50 km
Electric motor power: 102 hp @ 2500 rpm.
Electric motor Torque: 330 nm
Average Energy consumption: 11.4-12 kWh/100 km
Electric motor location: Between the combustion Engine and the transmission
Electric motor type: Synchronous
Average Energy consumption (NEDC, WLTP equivalent): 11.4-12 kWh/100 km
All-electric range (NEDC, WLTP equivalent): 45-50 km
Maximum revolutions of the electric motor: 7000 rpm.
Space:
Kerb Weight (kg): 1540
Max. weight (kg): 2040
Max. roof load: 75 kg
Max load (kg): 500
Trunk (boot) space - maximum: 1162 l
Trunk (boot) space - minimum: 272 l
Permitted trailer load with brakes (12%): 1500 kg
Fuel tank capacity: 40 l
Permitted trailer load without brakes: 750 kg
Permitted towbar download: 80 kg
Permitted trailer load with brakes (8%): 1700 kg
dimensions:
Length: 4276 mm
Width: 1799 mm
Height: 1484 mm
wheelbase: 2630 mm
Width including mirrors: 2027 mm
Front track: 1533-1549 mm
Rear (Back) track: 1503-1521 mm
Ride height (ground clearance): 140 mm
Minimum turning circle (turning diameter): 10.9 m
Powertrain, Suspension and Brakes:
Drivetrain Architecture: The Internal combustion Engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 6 gears, automatic transmission DSG
Front brakes: Ventilated discs
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: 205/55 R16; 225/45 R17; 225/40 R18
Wheel rims size: 6.5J x 16; 7.5J x 17; 7.5J x 18
Front suspension: Independent, type McPherson with coil Spring and anti-roll bar
Rear suspension: Independent multi-link Spring suspension with stabilizer
