Everything you need to know about specifications and performance - Toyota Sienna 2003 - 3.3 i V6 24V (233 Hp)

Full specifications and technical details 2003 Toyota Sienna II 3.3 i V6 24V (233 Hp)

Overview:

What is the engine capacity of a Toyota Sienna 2003?
The engine capacity of the Toyota Sienna 2003 is 3303.

Toyota Sienna 2003 How many horsepower?
The engine power of the Toyota Sienna 2003 is 233 Hp @ 5600 rpm..

What is the Toyota Sienna 2003 engine?
Toyota Sienna 2003 engine is 3MZ-FE. (Click to see other cars using the same engine)

What is the recommended oil for a Toyota Sienna 2003 engine?
The recommended oil for a Toyota Sienna 2003 car engine is 5W-30.

What type of camshaft transmission system is used in a Toyota Sienna 2003 engine?
belt is used to transmit motion.

General:

Brand: Toyota

Model: Sienna

Generation: II

Modification (Engine): 3.3 i V6 24V (233 Hp)

Start of production: January, 2003

End of production: 2006

Powertrain Architecture: Internal Combustion Engine

Body type:Mini van

Seats: 8

Doors: 5

Engine:

Power: 233 hp @ 5600 rpm.

Power per litre: 70.5 hp/l

Torque: 328 nm @ 3600 rpm.

Engine Model/Code:3MZ-FE

Engine displacement: 3303

Number of cylinders: 6

Engine configuration: V-engine

Number of valves per cylinder: 4

Fuel injection system: Multi-port manifold injection

Engine aspiration: Naturally aspirated Engine

Engine oil capacity: 4.7 l

Coolant: 11.7 l

Engine layout: Front, Transverse

Cylinder Bore: 92 mm

Piston Stroke: 83 mm

Compression ratio: 10.8:1

recommended engine oil: 5W-30

euro standards: EURO 3/4

engine lifespan (km): ~400 000

weight (kg): 177

timing drive: belt

Show more details about this engine

Performance:

Fuel Type: Petrol (Gasoline)

Fuel consumption (economy) - urban: 12.4 l/100 km

Fuel consumption (economy) - extra urban: 8.7 l/100 km

Maximum speed: 178 km/h

Weight-to-power ratio: 8.2 kg/Hp, 122 Hp/tonne

Weight-to-torque ratio: 5.8 kg/Nm, 171.7 Nm/tonne

Space:

Kerb Weight (kg): 1910

Trunk (boot) space - maximum: 4217 l

Trunk (boot) space - minimum: 1235 l

Fuel tank capacity: 76 l

dimensions:

Length: 5080 mm

Width: 1966 mm

Height: 1750 mm

wheelbase: 3030 mm

Front track: 1666 mm

Rear (Back) track: 1700 mm

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.

Drive wheel: Front wheel drive

Number of gears and type of gearbox: 5 gears, automatic transmission

Front brakes: Disc

Rear brakes: Disc

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Tires size: 215/65 R16

Front suspension: Spring Strut

Rear suspension: Transverse stabilizer
