Toyota Land Cruiser J80 4.2 TD 24V (170 Hp) 4WD
Overall Rating
Toyota Land Cruiser:
The Toyota Land Cruiser , also sometimes spelt as LandCruiser, is a series of four-wheel drive vehicles produced by the Japanese automobile manufacturer Toyota. It is Toyota's longest running series of models. As of 2019, the sales of the Land Cruiser totalled more than 10 million units worldwide.
Production of the first generation of the Land Cruiser began in 1951. The Land Cruiser has been produced in convertible, hardtop, station wagon and cab chassis body styles. The Land Cruiser's reliability and longevity have led to huge popularity, especially in Australia, where it is the best-selling body-on-frame, four-wheel drive vehicle. Toyota also extensively tests the Land Cruiser in the Australian outback – considered to be one of the toughest operating environments in both temperature and terrain. In Japan, the Land Cruiser was once exclusive to Toyota Japanese dealerships called Toyota Store....(Read more on Wikipedia)
J80 Overview:
Toyota Land Cruiser (J80). With 380 Nm of torque, it offers ample pulling power. At around 2200 kg, it’s on the heavier side. All‑wheel drive provides excellent grip, ideal for off‑road use. Acceleration is relatively slow (0–100 km/h in 12.7 s). The top speed reaches 170 km/h. A sport utility vehicle offering higher ground clearance and versatile cargo space. Seating for 5 makes it ideal for daily use.
4.2 TD 24V (170 Hp) 4WD Verdict:
Performance Verdict
A highly sought-after engine offering a strong blend of power and torque, with improved responsiveness over earlier diesels, making it a balanced performer.
Fuel Economy
Excellent fuel economy for its class, making it a cost-effective option for daily driving and adventurous expeditions.
Pros and Cons:
Pros:
- • Legendary reliability and durability
- • Exceptional off-road capability
- • Spacious and comfortable interior for its class
- • Robust body-on-frame construction
- • Strong resale value
Cons:
- • High fuel consumption for petrol engines
- • Some diesel variants can be underpowered or slow
- • Large size can be challenging in urban environments
- • Dated interior and safety features by modern standards
- • Maintenance can be costly for specific parts
Specifications:
Specifications are compared to those of the previous generation(J70, J73: 1993 - 1996).
| General: | |
|---|---|
| Brand: | Toyota |
| Model: | Land Cruiser |
| Generation: | J80 |
| Modification (Engine): | 4.2 TD 24V (170 Hp) 4WD |
| Start of production: | 1995 |
| End of production: | 1996 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | SUV |
| Seats: | 5 |
| Doors: | 5 |
| Engine: | |
|---|---|
| Power: | 170 Hp @ 3600 rpm. Same horsepower |
| Power per litre: | 40.8 Hp/l [845mm more] |
| Torque: | 380 Nm @ 2500 rpm. |
| Engine Model/Code: | 1HD-FT More details about the engine 1HD-FT |
| Engine displacement: | 4164 |
| Number of cylinders: | 6 |
| Engine configuration: | Inline |
| Number of valves per cylinder: | 4 |
| Fuel injection system: | Direct injection |
| Engine aspiration: | Turbocharger |
| Valvetrain: | OHV |
| Engine oil capacity: | 9.7 l |
| Engine layout: | Front, Longitudinal |
| Cylinder Bore: | 94 mm |
| Piston Stroke: | 100 mm |
| Compression ratio: | 18.6:1 |
| Performance: | |
|---|---|
| Fuel Type: | Diesel |
| Fuel consumption (economy) - combined: | 11.2 l/100 km |
| Acceleration 0 - 100 km/h: | 12.7 sec |
| Acceleration 0 - 62 mph: | 12.7 sec |
| Maximum speed: | 170 km/h |
| Weight-to-power ratio: | 12.9 kg/Hp, 77.3 Hp/tonne |
| Weight-to-torque ratio: | 5.8 kg/Nm, 172.7 Nm/tonne |
| Acceleration 0 - 60 mph: | 12.1 sec |
| Space: | |
|---|---|
| Kerb Weight: | 2200 |
| Max. weight: | 3060 |
| Max load: | 860 |
| Trunk (boot) space - maximum: | 1368 l |
| Trunk (boot) space - minimum: | 832 l |
| Fuel tank capacity: | 95 l |
| Size: | |
|---|---|
| Length: | 4820 mm [845mm more] |
| Width: | 1930 mm [240mm more] |
| Height: | 1890 mm [20mm more] |
| Wheelbase: | 2850 mm [540mm more] |
| Front track: | 1595 mm |
| Rear (Back) track: | 1600 mm |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4x4) |
| Number of gears | 5 |
| Transmission type | Manual |
| Front brakes | Ventilated discs [Best for performance and cooling.] |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Cone worm with recirculation balls |
| Power steering | Hydraulic Steering |
| Tires size | 275/70 R16 |
| Wheel rims size | 8J x 16 |
| Front suspension | Dependent spring suspension with anti-roll bar |
| Rear suspension | dependent spring suspension, Transverse stabilizer |
