Everything you need to know about specifications and performance - Toyota Corolla 2012 - 1.4 D-4D (90 Hp)

Full specifications and technical details 2012 Toyota Corolla XI (E170) 1.4 D-4D (90 Hp)

Overview:

What is the engine capacity of a Toyota Corolla 2012?
The engine capacity of the Toyota Corolla 2012 is 1364.

Toyota Corolla 2012 How many horsepower?
The engine power of the Toyota Corolla 2012 is 90 Hp @ 3800 rpm..

What is the Toyota Corolla 2012 engine?
Toyota Corolla 2012 engine is 1ND-TV. (Click to see other cars using the same engine)

How much gasoline does a Toyota Corolla 2012 consume?
The Toyota Corolla 2012 consumes 4.1 liters of gasoline per 100 km

General:

Brand: Toyota

Model: Corolla

Generation: XI (E170)

Modification (Engine): 1.4 D-4D (90 Hp)

Start of production: 2012

End of production: 2015

Powertrain Architecture: Internal Combustion Engine

Body type:Sedan

Seats: 5

Doors: 4

Engine:

Engine systems: Particulate filter

Power: 90 hp @ 3800 rpm.

Power per litre: 66 hp/l

Torque: 205 nm @ 1800-2800 rpm.

Engine Model/Code:1ND-TV

Engine displacement: 1364

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 2

Fuel injection system: Diesel Commonrail

Engine aspiration: Turbocharger, Intercooler

Valvetrain: SOHC

Engine oil capacity: 3.7 l

Coolant: 5.6 l

Engine layout: Front, Transverse

Cylinder Bore: 73 mm

Piston Stroke: 81.5 mm

Compression ratio: 16.5:1

Performance:

Fuel Type: Diesel

Fuel consumption (economy) - urban: 4.9 l/100 km

Fuel consumption (economy) - extra urban: 3.6 l/100 km

Fuel consumption (economy) - combined: 4.1 l/100 km

Emission standard: Euro 5 J

Acceleration 0 - 100 km/h: 12.5 sec

Acceleration 0 - 62 mph: 12.5 sec

Maximum speed: 180 km/h

Weight-to-power ratio: 14.4 kg/Hp, 69.2 Hp/tonne

Weight-to-torque ratio: 6.3 kg/Nm, 157.7 Nm/tonne

Acceleration 0 - 60 mph: 11.9 sec

Space:

Kerb Weight (kg): 1300

Max. weight (kg): 1780

Max load (kg): 480

Trunk (boot) space - minimum: 452 l

Fuel tank capacity: 55 l

dimensions:

Length: 4620 mm

Width: 1775 mm

Height: 1465 mm

wheelbase: 2700 mm

Front track: 1535 mm

Rear (Back) track: 1535 mm

Ride height (ground clearance): 125 mm

Minimum turning circle (turning diameter): 10.8 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.

Drive wheel: Front wheel drive

Number of gears and type of gearbox: 6 gears, manual transmission

Front brakes: Ventilated discs

Rear brakes: Disc

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Tires size: 195/65 R15; 205/55 R16

Wheel rims size: 15; 16

Front suspension: Independent, type McPherson with coil Spring and anti-roll bar

Rear suspension: Torsion
