Kia Carnival IV 3.5i Smartstream V6 (294 Hp) Automatic 9 Seat
Overall Rating
Kia Carnival:
The Kia Carnival is a minivan manufactured by the Korean automaker Kia since 1998. It is marketed globally under various nameplates, prominently as the Kia Sedona.
The first-generation Carnival was introduced in January 1998, and was marketed in a single, short wheelbase version. Second-generation models were marketed in short and long wheelbase variants. A rebadged variant of the second generation was offered in North America as the Hyundai Entourage. Beginning in 2010, the second-generation model received updated equipment, including Kia's corporate Tiger Nose grille, as introduced by its then new design chief, Peter Schreyer. Kia introduced its third-generation minivan in 2014, solely in a long wheelbase format. The fourth generation was introduced in 2020, when Kia also began using the Carnival nameplate worldwide....(Read more on Wikipedia)
IV Overview:
Kia Carnival (IV). With 355 Nm of torque, it offers ample pulling power. With a weight of 2000 kg, it falls in the mid‑range. Front‑wheel drive delivers efficiency and easy handling. A spacious vehicle designed to transport passengers comfortably, often with sliding doors. With seating for 9, it’s perfect for larger families.
The Kia Carnival IV has not been directly tested by Euro NCAP. However, its counterpart, the Kia Carnival, received a 5-star safety rating from ANCAP (Australasian New Car Assessment Program) in 2021, indicating strong safety performance.
3.5i Smartstream V6 (294 Hp) Automatic 9 Seat Verdict:
Performance Verdict
The V6 engine provides ample power for the 9-seat configuration, ensuring smooth and capable performance for family trips and daily driving.
Fuel Economy
Fuel consumption is consistent with the other V6 variants, representing a trade-off for its strong performance, especially with more passengers.
Pros and Cons:
Pros:
- • Spacious and highly versatile interior with multiple seating configurations
- • Modern, SUV-inspired exterior design stands out in the minivan segment
- • Choice of powerful V6 petrol or fuel-efficient diesel engine options
- • Comfortable ride quality, ideal for long journeys
- • Advanced technology and safety features available
Cons:
- • V6 petrol engine can be thirsty, especially in urban driving
- • Large dimensions can make parking and maneuvering in tight spaces challenging
- • No all-wheel-drive (AWD) option available in some markets
- • Some interior materials on lower trims could feel more premium
Specifications:
Specifications are compared to those of the previous generation(Grand Carnival III (facelift 2018): 2018 - 2020).
| General: | |
|---|---|
| Brand: | Kia |
| Model: | Carnival |
| Generation: | IV |
| Modification (Engine): | 3.5i Smartstream V6 (294 Hp) Automatic 9 Seat |
| Start of production: | June, 2020 |
| End of production: | 2024 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | Minivan |
| Seats: | 9 |
| Doors: | 5 |
| Engine: | |
|---|---|
| Engine systems: | Start & Stop System |
| Power: | 294 Hp @ 6400 rpm. Same horsepower |
| Power per litre: | 84.7 Hp/l [40mm more] |
| Torque: | 355 Nm @ 5200 rpm. |
| Engine Model/Code: | G6DT More details about the engine G6DT |
| Engine displacement: | 3470 |
| Number of cylinders: | 6 |
| Engine configuration: | V-engine |
| Fuel injection system: | Direct injection |
| Engine aspiration: | Naturally aspirated engine |
| Engine oil capacity: | 6.1 l |
| Coolant: | 8.6 l |
| Engine layout: | Front, Longitudinal |
| Performance: | |
|---|---|
| Fuel Type: | Petrol (Gasoline) |
| Fuel consumption (economy) - urban: | 12.5 l/100 km |
| Fuel consumption (economy) - extra urban: | 9.1-9.2 l/100 km |
| Fuel consumption (economy) - combined: | 11 l/100 km |
| Weight-to-power ratio: | 6.8 kg/Hp, 147 Hp/tonne |
| Weight-to-torque ratio: | 5.6 kg/Nm, 177.5 Nm/tonne |
| Space: | |
|---|---|
| Kerb Weight: | 2000 |
| Size: | |
|---|---|
| Length: | 5155 mm [40mm more] |
| Width: | 1995 mm [10mm more] |
| Height: | 1740 mm [Same height.] |
| Wheelbase: | 3090 mm [30mm more] |
| Front track: | 1741-1746 mm |
| Rear (Back) track: | 1741-1746 mm |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears | 8 |
| Transmission type | Automatic |
| Front brakes | Ventilated discs [Best for performance and cooling.] |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 235/60 R18; 235/55 R19 |
| Wheel rims size | 18; 19 |
| Front suspension | Independent type McPherson |
| Rear suspension | Independent multi-link suspension |
