Jeep Wagoneer WS 5.7 V8 HEMI (397 Hp) eTorque TorqueFlite
Jeep Wagoneer:
The Jeep Wagoneer and Grand Wagoneer are a sport utility vehicle nameplate of Jeep vehicles, with several models marketed for the 1963 through 1993 model years and again since the 2022 model year.
Various versions of the Wagoneer/Grand Wagoneer were manufactured in the US and other nations by Kaiser Motors , by American Motors , by Chrysler , and Stellantis from 2021.
A revival of the Jeep Wagoneer was introduced as a concept version on September 3, 2020, and as the production model on March 11, 2021. Sales began in the second half of 2021 for the 2022 model year. In 2024, Jeep added an all-electric vehicle called the Wagoneer S to the lineup....(Read more on Wikipedia)
WS Overview:
Jeep Wagoneer (WS). With 548 Nm of torque, it offers ample pulling power. At around 2712 kg, it’s on the heavier side. Rear‑wheel drive offers dynamic handling and sporty feedback. A sport utility vehicle offering higher ground clearance and versatile cargo space. With seating for 7, it’s perfect for larger families.
Pros and Cons:
Pros:
- • High-performance engine delivering 397 hp.
- • Rear-wheel drive layout for enhanced handling and balance.
- • Independent multi-link suspension for premium ride comfort.
- • Ventilated disc brakes for reliable cooling and stopping power.
- • Generous trunk capacity of 776 Liters.
Cons:
- • Relatively high fuel consumption: 13.1 L/100 km combined.
- • Meets LEV II emission standard; check for local urban restriction zones.
Specifications:
Specifications are compared to those of the previous generation(L (WS): April, 2022 - ).
| General: |
| Brand: | Jeep |
|---|
| Model: | Wagoneer |
|---|
| Generation: | WS |
|---|
| Modification (Engine): | 5.7 V8 HEMI (397 Hp) eTorque TorqueFlite |
|---|
| Start of production: | March, 2021 |
|---|
| End of production: | November, 2023 |
|---|
| Powertrain Architecture: | MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV) |
|---|
| Body type: | SUV |
|---|
| Seats: | 7-8 |
|---|
| Doors: | 5 |
|---|
| Engine: |
| Engine systems: | Start & Stop System |
|---|
| Power: | 397 Hp @ 5600 rpm. Same horsepower |
|---|
| Power per litre: | 70.2 Hp/l [306mm less] |
|---|
| Torque: | 548 Nm @ 3950 rpm. |
|---|
| Engine Model/Code: | EZL More details about the engine EZL |
|---|
| Engine displacement: | 5654 |
|---|
| Number of cylinders: | 8 |
|---|
| Engine configuration: | V-engine |
|---|
| Number of valves per cylinder: | 2 |
|---|
| Fuel injection system: | Multi-port manifold injection |
|---|
| Valvetrain: | VCT |
|---|
| Engine oil capacity: | 6.6 l |
|---|
| Coolant: | 16 l |
|---|
| Engine layout: | Front, Longitudinal |
|---|
| Cylinder Bore: | 99.5 mm |
|---|
| Piston Stroke: | 90.9 mm |
|---|
| Compression ratio: | 10.5:1 |
|---|
| Maximum engine speed: | 5800 rpm. |
|---|
| Performance: |
| Fuel Type: | Petrol (Gasoline) |
|---|
| Fuel consumption (economy) - urban: | 14.7 l/100 km |
|---|
| Fuel consumption (economy) - extra urban: | 10.7 l/100 km |
|---|
| Fuel consumption (economy) - combined: | 13.1 l/100 km |
|---|
| Emission standard: | LEV II |
|---|
| Weight-to-power ratio: | 6.8 kg/Hp, 146.9 Hp/tonne |
|---|
| Weight-to-torque ratio: | 4.9 kg/Nm, 202.7 Nm/tonne |
|---|
| Space: |
| Kerb Weight: | 2703-2722 |
|---|
| Max. weight: | 3402 |
|---|
| Max load: | 680-699 |
|---|
| Trunk (boot) space - maximum: | 3305 l |
|---|
| Trunk (boot) space - minimum: | 776 l |
|---|
| Permitted trailer load with brakes (12%): | 4536 kg |
|---|
| Fuel tank capacity: | 100 l |
|---|
| Size: |
| Ramp-over (brakeover) angle: | 18.5-22° |
|---|
| Length: | 5453 mm [306mm less] |
|---|
| Width: | 2124 mm [Same width.] |
|---|
| Height: | 1921 mm [42mm less] |
|---|
| Wheelbase: | 3124 mm [179mm less] |
|---|
| Width including mirrors: | 2388 mm |
|---|
| Front track: | 1740 mm |
|---|
| Rear (Back) track: | 1734 mm |
|---|
| Ride height (ground clearance): | 211-254 mm |
|---|
| Minimum turning circle (turning diameter): | 11.6 m [above average] |
|---|
| Approach angle: | 21.5-25° |
|---|
| Departure angle: | 21.1-24° |
|---|
| Powertrain: |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the rear wheels of the car with the ability to work only in mixed mode. |
|---|
| Drive wheel | Rear wheel drive |
|---|
| Number of gears | 8 |
|---|
| Transmission type | Automatic |
|---|
| Gearbox type | TorqueFlite |
|---|
| Front brakes | Ventilated discs, 378x30 mm [Best for performance and cooling.] |
|---|
| Rear brakes | Disc, 375x22 mm [above average] |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 275/55 R20 |
|---|
| Wheel rims size | 9J x 20 |
|---|
| Front suspension | Independent coil spring, Transverse stabilizer |
|---|
| Rear suspension | Independent multi-link spring suspension with stabilizer |
|---|
| Electric: |
| Electric motor power: | 16 Hp |
|---|
| Electric motor Torque: | 176 Nm |
|---|
| Electric motor location: | Front, Transverse |
|---|
