Hyundai Sonata IV (EF) 2.5 V6 (175 Hp) Automatic
Overall Rating
Hyundai Sonata:
The Hyundai Sonata is a mid-size car that has been manufactured by Hyundai since 1985. The first generation Sonata, which was introduced in 1985, was a facelifted version of the Hyundai Stellar with an engine upgrade, and was withdrawn from the market in two years due to poor customer reaction. While the nameplate was originally only sold in South Korea, the second generation of 1988 was widely exported.
The Sonata is currently manufactured in South Korea, China, and Pakistan. It was named after the musical term, sonata. It was formerly manufactured in the United States from 2005 until 2022, though after 2022, American production was phased out....(Read more on Wikipedia)
IV (EF) Overview:
Hyundai Sonata (IV (EF)). With 230 Nm of torque, it offers ample pulling power. With a weight of 1370 kg, it falls in the mid‑range. Front‑wheel drive delivers efficiency and easy handling. A four-door car with a separate trunk, ideal for families and daily commuting. Seating for 5 makes it ideal for daily use.
2.5 V6 (175 Hp) Automatic Verdict:
Performance Verdict
Combines the strong 175 Hp V6 with the convenience of an automatic, providing effortless cruising.
Fuel Economy
The most powerful V6 with an automatic transmission results in the highest fuel consumption figures.
Pros and Cons:
Pros:
- • Spacious and comfortable interior
- • Smooth ride quality
- • Good value for money on the used market
- • Reliable V6 engine options
- • Decent standard features for its class
Cons:
- • Uninspired handling dynamics
- • Higher fuel consumption for V6 models
- • Interior plastics can feel dated
- • Lack of official Euro NCAP safety rating
- • Some engine variants can feel underpowered
Specifications:
Specifications are compared to those of the previous generation(III (Y3, facelift 1996): 1996 - 1998).
| General: | |
|---|---|
| Brand: | Hyundai |
| Model: | Sonata |
| Generation: | IV (EF) |
| Modification (Engine): | 2.5 V6 (175 Hp) Automatic |
| Start of production: | 1998 |
| End of production: | 2001 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | Sedan |
| Seats: | 5 |
| Doors: | 4 |
| Engine: | |
|---|---|
| Power: | 175 Hp @ 6000 rpm. Same horsepower |
| Power per litre: | 70.2 Hp/l [10mm more] |
| Torque: | 230 Nm @ 4000 rpm. |
| Engine Model/Code: | Delta / G6BV More details about the engine Delta / G6BV |
| Engine displacement: | 2494 |
| Number of cylinders: | 6 |
| Engine configuration: | V-engine |
| Number of valves per cylinder: | 4 |
| Fuel injection system: | Multi-port manifold injection |
| Engine aspiration: | Naturally aspirated engine |
| Valvetrain: | DOHC |
| Engine oil capacity: | 4.5 l |
| Engine layout: | Front, Transverse |
| Cylinder Bore: | 84 mm mm |
| Piston Stroke: | 75 mm mm |
| Compression ratio: | 10:1 |
| Performance: | |
|---|---|
| Fuel Type: | Petrol (Gasoline) |
| Weight-to-power ratio: | 7.8 kg/Hp, 127.7 Hp/tonne |
| Weight-to-torque ratio: | 6 kg/Nm, 167.9 Nm/tonne |
| Space: | |
|---|---|
| Kerb Weight: | 1370 |
| Trunk (boot) space - minimum: | 396 l |
| Fuel tank capacity: | 65 l |
| Size: | |
|---|---|
| Length: | 4710 mm mm [10mm more] |
| Width: | 1818 mm mm [48mm more] |
| Height: | 1410 mm mm [5mm more] |
| Wheelbase: | 2700 mm mm [Same wheelbase.] |
| Front track: | 1540 mm |
| Rear (Back) track: | 1520 mm |
| Minimum turning circle (turning diameter): | 10.5 m [above average] |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears | 4 |
| Transmission type | Automatic |
| Front brakes | Ventilated discs [Best for performance and cooling.] |
| Rear brakes | Disc [above average] |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/60 R15 |
| Wheel rims size | 15 |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link suspension |
