Everything you need to know about specifications and performance - Citroen ZX 1992 - 1.9 D (71 Hp)
Overview:
What is the engine capacity of a Citroen ZX 1992?
The engine capacity of the Citroen ZX 1992 is 1905.
Citroen ZX 1992 How many horsepower?
The engine power of the Citroen ZX 1992 is 71 Hp @ 4600 rpm..
What is the Citroen ZX 1992 engine?
Citroen ZX 1992 engine is D9B XUD9A/L. (Click to see other cars using the same engine)
General:
Brand: Citroen
Model: ZX
Generation: (N2, Phase I) 3-door
Modification (Engine): 1.9 D (71 Hp)
Start of production: 1992
End of production: 1994
Powertrain Architecture: Internal Combustion Engine
Body type:Hatchback
Seats: 5
Doors: 3
Engine:
Power: 71 hp @ 4600 rpm.
Power per litre: 37.3 hp/l
Torque: 120 nm @ 2000 rpm.
Engine Model/Code:D9B XUD9A/L
Engine displacement: 1905
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 2
Fuel injection system: Precombustion chamber injection
Engine aspiration: Naturally aspirated Engine
Valvetrain: OHC
Engine oil capacity: 4.3 l
Coolant: 8.5 l
Engine layout: Front, Transverse
Cylinder Bore: 83 mm
Piston Stroke: 88 mm
Compression ratio: 23:1
Performance:
Fuel Type: Diesel
Weight-to-power ratio: 14.4 kg/Hp, 69.6 Hp/tonne
Weight-to-torque ratio: 8.5 kg/Nm, 117.6 Nm/tonne
Space:
Kerb Weight (kg): 1020
Max. weight (kg): 1505
Max. roof load: 75 kg
Max load (kg): 485
Trunk (boot) space - maximum: 1146 l
Trunk (boot) space - minimum: 324 l
Permitted trailer load with brakes (12%): 1000 kg
Fuel tank capacity: 56 l
Permitted trailer load without brakes: 510 kg
Permitted towbar download: 70 kg
dimensions:
Length: 4071 mm
Width: 1702 mm
Height: 1397 mm
wheelbase: 2540 mm
Front track: 1414 mm
Rear (Back) track: 1407 mm
Front overhang: 849 mm
Rear overhang: 682 mm
Ride height (ground clearance): 119 mm
Minimum turning circle (turning diameter): 11.3 m
Powertrain, Suspension and Brakes:
Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 5 gears, manual transmission
Front brakes: Disc
Rear brakes: Drum
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Hydraulic Steering
Tires size: 165/70 R13
Front suspension: Independent type McPherson, Wishbone
Rear suspension: Hydro-pneumatic element, Trailing arm
