Everything you need to know about specifications and performance - Alfa Romeo Giulietta 2010 - 2.0 JTDM (140 Hp)

Full specifications and technical details 2010 Alfa Romeo Giulietta (Type 940) 2.0 JTDM (140 Hp)

Overview:

What is the engine capacity of a Alfa Romeo Giulietta 2010?
The engine capacity of the Alfa Romeo Giulietta 2010 is 1956.

Alfa Romeo Giulietta 2010 How many horsepower?
The engine power of the Alfa Romeo Giulietta 2010 is 140 Hp @ 3750 rpm..

What is the Alfa Romeo Giulietta 2010 engine?
Alfa Romeo Giulietta 2010 engine is 940A5000. (Click to see other cars using the same engine)

How much gasoline does a Alfa Romeo Giulietta 2010 consume?
The Alfa Romeo Giulietta 2010 consumes 4.5 liters of gasoline per 100 km

General:

Brand: Alfa Romeo
Model: Giulietta
Generation: Type 940
Modification (Engine): 2.0 JTDM (140 Hp)
Start of production: 2010
End of production: 2013
Powertrain Architecture: Internal Combustion Engine
Body type:Hatchback
Seats: 5
Doors: 5

Engine:

Engine systems: Particulate filter
Power: 140 hp @ 3750 rpm.
Power per litre: 71.6 hp/l
Torque: 320 nm @ 1500 rpm.
Engine Model/Code:940A5000
Engine displacement: 1956
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 4
Fuel injection system: Diesel Commonrail
Engine aspiration: Turbocharger, Intercooler
Engine oil capacity: 4.2 l
Coolant: 6.7 l
Engine layout: Front, Transverse
Cylinder Bore: 83 mm
Piston Stroke: 90.4 mm
Compression ratio: 16.5:1

Performance:

Fuel Type: Diesel
Fuel consumption (economy) - urban: 5.6 l/100 km
Fuel consumption (economy) - extra urban: 3.9 l/100 km
Fuel consumption (economy) - combined: 4.5 l/100 km
Emission standard: Euro 5
Acceleration 0 - 100 km/h: 9 sec
Acceleration 0 - 62 mph: 9 sec
Maximum speed: 205 km/h
Weight-to-power ratio: 9.4 kg/Hp, 106.1 Hp/tonne
Weight-to-torque ratio: 4.1 kg/Nm, 242.4 Nm/tonne
Acceleration 0 - 60 mph: 8.6 sec

Space:

Kerb Weight (kg): 1320
Max. weight (kg): 1825
Max load (kg): 505
Trunk (boot) space - minimum: 350 l
Fuel tank capacity: 60 l

dimensions:

Length: 4351 mm
Width: 1798 mm
Height: 1465 mm
wheelbase: 2634 mm
Front track: 1554 mm
Rear (Back) track: 1554 mm
Minimum turning circle (turning diameter): 10.9 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 6 gears, manual transmission
Front brakes: Ventilated discs
Rear brakes: Ventilated discs
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: 205/55 R16 91V
Wheel rims size: 7J x 16
Front suspension: Independent type McPherson
Rear suspension: Independent multi-link Spring suspension with stabilizer
