Everything you need to know about specifications and performance - Renault Master 2015 - 2.3 Energy dCi (145 Hp)

Overview:

What is the engine capacity of a Renault Master 2015?
The engine capacity of the Renault Master 2015 is 2298.

Renault Master 2015 How many horsepower?
The engine power of the Renault Master 2015 is 145 Hp @ 3500 rpm..

What is the Renault Master 2015 engine?
Renault Master 2015 engine is M9T. (Click to see other cars using the same engine)

What is the recommended oil for a Renault Master 2015 engine?
The recommended oil for a Renault Master 2015 car engine is 5W-30, 5W-40.

What type of camshaft transmission system is used in a Renault Master 2015 engine?
chain is used to transmit motion.

General:

Brand: Renault

Model: Master

Generation: III (Phase II, 2014) Bus

Modification (Engine): 2.3 Energy dCi (145 Hp)

Start of production: 2015

End of production: 2018

Powertrain Architecture: Internal Combustion Engine

Body type:Multi Purpose Vehicle (MPV)

Seats: 17

Doors: 4

Engine:

Engine systems: Particulate filter

Power: 145 hp @ 3500 rpm.

Power per litre: 63.1 hp/l

Torque: 360 nm @ 1500-2500 rpm.

Engine Model/Code:M9T

Engine displacement: 2298

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Diesel Commonrail

Engine aspiration: Turbocharger, Intercooler

Engine oil capacity: 8 l

Coolant: 11 l

recommended engine oil: 5W-30, 5W-40

euro standards: EURO 4/5/6

engine lifespan (km): ~400 000

weight (kg): 217

timing drive: chain

Show more details about this engine

Performance:

Fuel Type: Diesel

Emission standard: Euro 6

Maximum speed: 100 km/h

Weight-to-power ratio: 18.3 kg/Hp, 54.5 Hp/tonne

Weight-to-torque ratio: 7.4 kg/Nm, 135.3 Nm/tonne

Space:

Kerb Weight (kg): 2660

Max. weight (kg): 3960

Max load (kg): 1300

Fuel tank capacity: 80 l

dimensions:

Length: 6198 mm

Width: 2070 mm

Height: 2488 mm

wheelbase: 4332 mm

Width including mirrors: 2470 mm

Front track: 1750 mm

Rear (Back) track: 1730 mm

Front overhang: 842 mm

Rear overhang: 1024 mm

Ride height (ground clearance): 173 mm

Minimum turning circle (turning diameter): 15.7 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.

Drive wheel: Front wheel drive

Number of gears and type of gearbox: 6 gears, manual transmission

Front brakes: Ventilated discs, 302 mm

Rear brakes: Disc, 305 mm

Tires size: 225/65 R16

Wheel rims size: 16
