Volkswagen Tiguan 2019 - 1.5 TSI (150 Hp) ACT DSG specifications
Overview
What is the engine capacity of a Volkswagen Tiguan 2019?
The engine capacity of the Volkswagen Tiguan 2019 is 1495 cm.
Volkswagen Tiguan 2019 How many horsepower?
The engine power of the Volkswagen Tiguan 2019 is 150 Hp @ 5000 rpm..
What is the Volkswagen Tiguan 2019 engine?
Volkswagen Tiguan 2019 engine is EA211evo / DADA, DPCA. (Click to see other cars using the same engine)
How much gasoline does a Volkswagen Tiguan 2019 consume?
The Volkswagen Tiguan 2019 consumes 7.1 liters of gasoline per 100 km
General:
Brand
Volkswagen
Model
Tiguan
Generation
Tiguan II Allspace
Modification (Engine)
1.5 TSI (150 Hp) ACT DSG
Start of production
September, 2019
End of production
January, 2020
Powertrain Architecture
Internal Combustion engine
Body type
Seats
7
Doors
5
Engine:
Engine systems
Start & Stop System
Power
150 hp @ 5000 rpm.
Power per litre
100.3 hp/l
Torque
250 nm @ 1500-3500 rpm.
Engine Model/Code
Engine displacement
1495 cm
Number of cylinders
4
Engine configuration
Inline
Number of valves per cylinder
4
Fuel injection system
Direct injection
Engine aspiration
Turbocharger, Intercooler
Engine oil capacity
4.3 l
Engine layout
Front, Transverse
Cylinder Bore
74.5 mm
Piston Stroke
85.7 mm
Compression ratio
10.5
Performance:
Fuel Type
Petrol (Gasoline)
Fuel consumption (economy) - urban
8.5 l/100 km
Fuel consumption (economy) - extra urban
6.3 l/100 km
Fuel consumption (economy) - combined (NEDC)
7.1 l/100 km
Fuel consumption (economy) - urban (NEDC)
8.5 l/100 km
Fuel consumption (economy) - extra urban (NEDC)
6.3 l/100 km
Fuel consumption (economy) - combined
7.1 l/100 km
Emission standard
Euro 6
Acceleration 0 - 100 km/h
9.2 sec
Acceleration 0 - 62 mph
9.2 sec
Maximum speed
198 km/h
Weight-to-power ratio
10.5 kg/Hp, 95.2 Hp/tonne
Weight-to-torque ratio
6.3 kg/Nm, 158.7 Nm/tonne
Acceleration 0 - 60 mph
8.7 sec
Electric system:
Size and space:
Kerb Weight
1575 kg
Max. weight
2360 kg
Max. roof load
75 kg
Max load
785 kg
Trunk (boot) space - maximum
1775 l
Trunk (boot) space - minimum
230 l
Permitted trailer load with brakes (12%)
1800 kg
Fuel tank capacity
58 l
Permitted trailer load without brakes
750 kg
Permitted towbar download
100 kg
Dimensions:
Ramp-over (brakeover) angle
14.9°
Length
4701 mm
Width
1839 mm
Height
1674 mm
Wheelbase
2787 mm
Width including mirrors
2099 mm
Front track
1575-1585 mm
Rear (Back) track
1564-1574 mm
Ride height (ground clearance)
189 mm
Minimum turning circle (turning diameter)
11.9 m
Approach angle
16.9°
Departure angle
14.5°
Power transmission system, suspension and brake system:
Drivetrain Architecture
The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel
Front wheel drive
Number of gears and type of gearbox
7 gears, automatic transmission DSG
Front brakes
Ventilated discs
Rear brakes
Disc
Assisting systems
ABS (Anti-lock braking system)
Steering type
Steering rack and pinion
Power steering
Electric Steering
Tires size
215/65 R17; 235/55 R18
Wheel rims size
7J x 17; 7J x 18
