Everything you need to know about specifications and performance - Volvo S80 2003 - 2.4 20V (140 Hp) Automatic

Full specifications and technical details 2003 Volvo S80 (facelift 2003) 2.4 20V (140 Hp) Automatic

Overview:

What is the engine capacity of a Volvo S80 2003?
The engine capacity of the Volvo S80 2003 is 2435.

Volvo S80 2003 How many horsepower?
The engine power of the Volvo S80 2003 is 140 Hp @ 4500 rpm..

What is the Volvo S80 2003 engine?
Volvo S80 2003 engine is B5244S2. (Click to see other cars using the same engine)

How much gasoline does a Volvo S80 2003 consume?
The Volvo S80 2003 consumes 9.7 liters of gasoline per 100 km

What is the recommended oil for a Volvo S80 2003 engine?
The recommended oil for a Volvo S80 2003 car engine is 5W-30.

What type of camshaft transmission system is used in a Volvo S80 2003 engine?
belt is used to transmit motion.

General:

Brand: Volvo

Model: S80

Generation: facelift 2003

Modification (Engine): 2.4 20V (140 Hp) Automatic

Start of production: 2003

End of production: 2006

Powertrain Architecture: Internal Combustion Engine

Body type:Sedan

Seats: 5

Doors: 4

Engine:

Power: 140 hp @ 4500 rpm.

Power per litre: 57.5 hp/l

Torque: 220 nm @ 3300 rpm.

Engine Model/Code:B5244S2

Engine displacement: 2435

Number of cylinders: 5

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Multi-port manifold injection

Engine aspiration: Naturally aspirated Engine

Valvetrain: DOHC

Engine oil capacity: 5.5 l

Coolant: 8 l

Engine layout: Front, Transverse

Cylinder Bore: 83 mm

Piston Stroke: 90 mm

Compression ratio: 10.3:1

recommended engine oil: 5W-30

euro standards: EURO 3/4

engine lifespan (km): ~380 000

timing drive: belt

Show more details about this engine

Performance:

Fuel Type: Petrol (Gasoline)

Fuel consumption (economy) - urban: 13.7 l/100 km

Fuel consumption (economy) - extra urban: 7.4 l/100 km

Fuel consumption (economy) - combined: 9.7 l/100 km

Emission standard: Euro 4

Acceleration 0 - 100 km/h: 11.4 sec

Acceleration 0 - 62 mph: 11.4 sec

Maximum speed: 200 km/h

Weight-to-power ratio: 10.9 kg/Hp, 92 Hp/tonne

Weight-to-torque ratio: 6.9 kg/Nm, 144.6 Nm/tonne

Acceleration 0 - 60 mph: 10.8 sec

Space:

Kerb Weight (kg): 1521

Max. weight (kg): 2020

Max. roof load: 100 kg

Max load (kg): 499

Trunk (boot) space - maximum: 1126 l

Trunk (boot) space - minimum: 460 l

Permitted trailer load with brakes (12%): 1800 kg

Fuel tank capacity: 70 l

Permitted trailer load without brakes: 750 kg

Permitted towbar download: 75 kg

dimensions:

Length: 4822 mm

Width: 1832 mm

Height: 1452 mm

wheelbase: 2791 mm

Front track: 1570 mm

Rear (Back) track: 1548 mm

Front overhang: 964 mm

Rear overhang: 1067 mm

Minimum turning circle (turning diameter): 11.6 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.

Drive wheel: Front wheel drive

Number of gears and type of gearbox: 5 gears, automatic transmission

Front brakes: Ventilated discs, 288 mm

Rear brakes: Disc, 288 mm

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Hydraulic Steering

Tires size: 215/55 R16; 225/50 R17

Wheel rims size: 7J x 16; 7J x 17

Front suspension: Independent type McPherson

Rear suspension: Independent multi-link suspension
