Everything you need to know about specifications and performance - Volkswagen Touran 2010 - 1.6 TDI (105 Hp)
Overview:
What is the engine capacity of a Volkswagen Touran 2010?
The engine capacity of the Volkswagen Touran 2010 is 1598.
Volkswagen Touran 2010 How many horsepower?
The engine power of the Volkswagen Touran 2010 is 105 Hp @ 4400 rpm..
What is the Volkswagen Touran 2010 engine?
Volkswagen Touran 2010 engine is CAYC. (Click to see other cars using the same engine)
How much gasoline does a Volkswagen Touran 2010 consume?
The Volkswagen Touran 2010 consumes 5.3 liters of gasoline per 100 km
General:
Brand: Volkswagen
Model: Touran
Generation: Cross Touran I (facelift 2010)
Modification (Engine): 1.6 TDI (105 Hp)
Start of production: August, 2010
End of production: June, 2013
Powertrain Architecture: Internal Combustion Engine
Body type:Mini van
Seats: 5
Doors: 5
Engine:
Engine systems: Particulate filter
Power: 105 hp @ 4400 rpm.
Power per litre: 65.7 hp/l
Torque: 250 nm @ 1500-2500 rpm.
Engine Model/Code:CAYC
Engine displacement: 1598
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 4
Fuel injection system: Diesel Commonrail
Engine aspiration: Turbocharger, Intercooler
Valvetrain: DOHC
Engine oil capacity: 4.3 l
Engine layout: Front, Transverse
Cylinder Bore: 79.5 mm
Piston Stroke: 80.5 mm
Compression ratio: 16.5:1
Performance:
Fuel Type: Diesel
Fuel consumption (economy) - urban: 6.5 l/100 km
Fuel consumption (economy) - extra urban: 4.7 l/100 km
Fuel consumption (economy) - combined (NEDC): 5.3 l/100 km
Fuel consumption (economy) - urban (NEDC): 6.5 l/100 km
Fuel consumption (economy) - extra urban (NEDC): 4.7 l/100 km
Fuel consumption (economy) - combined: 5.3 l/100 km
Emission standard: Euro 5
Acceleration 0 - 100 km/h: 13.2 sec
Acceleration 0 - 62 mph: 13.2 sec
Maximum speed: 175 km/h
Weight-to-power ratio: 14.4 kg/Hp, 69.4 Hp/tonne
Weight-to-torque ratio: 6.1 kg/Nm, 165.1 Nm/tonne
Acceleration 0 - 60 mph: 12.5 sec
Space:
Kerb Weight (kg): 1514
Max. weight (kg): 2160
Max. roof load: 100 kg
Max load (kg): 646
Trunk (boot) space - maximum: 1989 l
Trunk (boot) space - minimum: 695 l
Permitted trailer load with brakes (12%): 1500 kg
Fuel tank capacity: 60 l
Permitted trailer load without brakes: 750 kg
Permitted towbar download: 75 kg
Permitted trailer load with brakes (8%): 1800 kg
dimensions:
Ramp-over (brakeover) angle: 10.6°
Length: 4406 mm
Width: 1799 mm
Height: 1685 mm
wheelbase: 2677 mm
Width including mirrors: 2081 mm
Front track: 1550 mm
Rear (Back) track: 1531 mm
Ride height (ground clearance): 152 mm
Minimum turning circle (turning diameter): 11.2 m
Approach angle: 13.5°
Departure angle: 16.9°
Powertrain, Suspension and Brakes:
Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 6 gears, manual transmission
Front brakes: Ventilated discs
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: Front wheel tires: 215/50 R17
Wheel rims size: Front wheel rims: 6.5J x 17
Front suspension: Coil spring, Wishbone, Transverse stabilizer
Rear suspension: Independent multi-link suspension, Transverse stabilizer
