Everything you need to know about specifications and performance - Ford C-MAX 2015 - 1.6 TDCi (115 Hp)

Full specifications and technical details 2015 Ford Grand C-MAX (facelift 2015) 1.6 TDCi (115 Hp)

Overview:

What is the engine capacity of a Ford C-MAX 2015?
The engine capacity of the Ford C-MAX 2015 is 1560.

Ford C-MAX 2015 How many horsepower?
The engine power of the Ford C-MAX 2015 is 115 Hp @ 3800 rpm..

What is the Ford C-MAX 2015 engine?
Ford C-MAX 2015 engine is T1DA, T1DB. (Click to see other cars using the same engine)

How much gasoline does a Ford C-MAX 2015 consume?
The Ford C-MAX 2015 consumes 4.9 liters of gasoline per 100 km

General:

Brand: Ford

Model: C-MAX

Generation: Grand C-MAX (facelift 2015)

Modification (Engine): 1.6 TDCi (115 Hp)

Start of production: 2015

End of production: 2019

Powertrain Architecture: Internal Combustion Engine

Body type:Multi Purpose Vehicle (MPV)

Seats: 5

Doors: 5

Engine:

Engine systems: Particulate filter

Power: 115 hp @ 3800 rpm.

Power per litre: 73.7 hp/l

Torque: 215 nm @ 1750 rpm.

Engine Model/Code:T1DA, T1DB

Engine displacement: 1560

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 2

Fuel injection system: Diesel Commonrail

Engine aspiration: Turbocharger, Intercooler

Valvetrain: DOHC

Engine oil capacity: 3.85 l

Coolant: 7.3 l

Engine layout: Front, Transverse

Cylinder Bore: 75 mm

Piston Stroke: 88.3 mm

Compression ratio: 16:1

Performance:

Fuel Type: Diesel

Fuel consumption (economy) - urban: 5.8 l/100 km

Fuel consumption (economy) - extra urban: 4.4 l/100 km

Fuel consumption (economy) - combined (NEDC): 4.9 l/100 km

Fuel consumption (economy) - urban (NEDC): 5.8 l/100 km

Fuel consumption (economy) - extra urban (NEDC): 4.4 l/100 km

Fuel consumption (economy) - combined: 4.9 l/100 km

Emission standard: Euro 6

Acceleration 0 - 100 km/h: 12.3 sec

Acceleration 0 - 62 mph: 12.3 sec

Maximum speed: 180 km/h

Weight-to-power ratio: 12.4 kg/Hp, 80.5 Hp/tonne

Weight-to-torque ratio: 6.6 kg/Nm, 150.5 Nm/tonne

Acceleration 0 - 60 mph: 11.7 sec

Space:

Kerb Weight (kg): 1429

Max. weight (kg): 2200

Max. roof load: 75 kg

Max load (kg): 771

Trunk (boot) space - maximum: 1787 l

Trunk (boot) space - minimum: 520 l

Permitted trailer load with brakes (12%): 1200 kg

Fuel tank capacity: 60 l

Permitted trailer load without brakes: 750 kg

Permitted towbar download: 75 kg

dimensions:

Length: 4519 mm

Width: 1828 mm

Height: 1642 mm

wheelbase: 2788 mm

Width with mirrors folded: 1858 mm

Width including mirrors: 2067 mm

Front track: 1543 mm

Rear (Back) track: 1554 mm

Minimum turning circle (turning diameter): 11.6 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.

Drive wheel: Front wheel drive

Number of gears and type of gearbox: 6 gears, manual transmission

Front brakes: Ventilated discs, 300x25 mm

Rear brakes: Disc, 280x11 mm

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Electric Steering

Tires size: 205/55 R16; 215/55 R16; 215/50 R17; 235/40 R18

Wheel rims size: 6.5J x 16; 7J x 16; 7J x 17; 8J x 18

Front suspension: Independent, type McPherson with coil Spring and anti-roll bar

Rear suspension: Independent multi-link Spring suspension with stabilizer
