Everything you need to know about specifications and performance - BMW 5 Series 2020 - 520i (170 Hp) Steptronic
Overview:
What is the engine capacity of a BMW 5 Series 2020?
The engine capacity of the BMW 5 Series 2020 is 1597.
BMW 5 Series 2020 How many horsepower?
The engine power of the BMW 5 Series 2020 is 170 Hp @ 5000-6000 rpm..
What is the BMW 5 Series 2020 engine?
BMW 5 Series 2020 engine is B48B16A. (Click to see other cars using the same engine)
How much gasoline does a BMW 5 Series 2020 consume?
The BMW 5 Series 2020 consumes 6.2-7.1 liters of gasoline per 100 km
General:
Engine:
Engine systems: Start & Stop System
Power: 170 hp @ 5000-6000 rpm.
Power per litre: 106.4 hp/l
Torque: 250 nm @ 2000-4700 rpm.
Engine Model/Code:B48B16A
Engine displacement: 1597
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 4
Fuel injection system: Direct injection
Engine aspiration: Twin-power turbo, Intercooler
Valvetrain: VALVETRONIC, Double-VANOS
Engine oil capacity: 5.25 l
Engine layout: Front, Longitudinal
Cylinder Bore: 82 mm
Piston Stroke: 75.6 mm
Compression ratio: 8.9:1
Performance:
Fuel Type: Petrol (Gasoline)
Fuel consumption (economy) - urban: 7.5-8.6 l/100 km
Fuel consumption (economy) - extra urban: 5.5-6.2 l/100 km
Combined fuel consumption (WLTP): 7.8 l/100 km
Fuel consumption (economy) - urban (NEDC, WLTP equivalent): 7.5-8.6 l/100 km
Fuel consumption (economy) - extra urban (NEDC, WLTP equivalent): 5.5-6.2 l/100 km
Fuel consumption (economy) - combined (NEDC, WLTP equivalent): 6.2-7.1 l/100 km
Fuel consumption (economy) - combined: 6.2-7.1 l/100 km
Emission standard: Euro 6d
Acceleration 0 - 100 km/h: 8.3 sec
Acceleration 0 - 62 mph: 8.3 sec
Maximum speed: 226 km/h
Weight-to-power ratio: 9.3 kg/Hp, 107.6 Hp/tonne
Weight-to-torque ratio: 6.3 kg/Nm, 158.2 Nm/tonne
Acceleration 0 - 60 mph: 7.9 sec
Space:
Kerb Weight (kg): 1580
Max. weight (kg): 2250
Max. roof load: 100 kg
Max load (kg): 670
Trunk (boot) space - minimum: 530 l
Permitted trailer load with brakes (12%): 2000 kg
Fuel tank capacity: 68 l
Permitted trailer load without brakes: 750 kg
Permitted towbar download: 90 kg
Permitted trailer load with brakes (8%): 2000 kg
dimensions:
Length: 4963 mm
Width: 1868 mm
Height: 1497 mm
wheelbase: 2975 mm
Width including mirrors: 2126 mm
Front track: 1606 mm
Rear (Back) track: 1631 mm
Front overhang: 882 mm
Rear overhang: 1106 mm
Minimum turning circle (turning diameter): 12.4 m
Powertrain, Suspension and Brakes:
Drivetrain Architecture: The Internal combustion Engine (ICE) drives the rear wheels of the vehicle.
Drive wheel: Rear wheel drive
Number of gears and type of gearbox: 8 gears, automatic transmission Steptronic
Front brakes: Ventilated discs
Rear brakes: Ventilated discs
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: Front wheel tires: 225/55 R17; 245/45 R18; 245/40 R19; 245/35 R20
Wheel rims size: Front wheel rims: 7.5J x 17; 8J x 18; 8J x 19; 8J x 20
Front suspension: Double wishbone, Transverse stabilizer
Rear suspension: Independent multi-link Spring suspension with stabilizer
